The reason pcm side is close to 5v when is connected to nothing is because pcm uses so called pull up internal resistor or some sort to connect it to 5v reference voltage internally which means when the pcm side connection is open, PCM will read close to 5v(5v minus voltage drop across the pull up resistor. If signal wire to pcm is intact, the sensor signal wire sends the signal voltage(bt 0 to 5v, this voltage will pull the PCM side voltage down to be same as the sensor signal voltage.
In Eric case it reacts the same way as I explained.
This is common practice across all computerized electronic sensing components. All are using pull up circuitry. it is fail safe, easy to diagnose. sample like when is open, the pcm reads 5v and pcm knows open wires.
reply
The reason pcm side is close to 5v when is connected to nothing is because pcm uses so called pull up internal resistor or some sort to connect it to 5v reference voltage internally which means when the pcm side connection is open, PCM will read close to 5v(5v minus voltage drop across the pull up resistor. If signal wire to pcm is intact, the sensor signal wire sends the signal voltage(bt 0 to 5v, this voltage will pull the PCM side voltage down to be same as the sensor signal voltage.
In Eric case it reacts the same way as I explained.
This is common practice across all computerized electronic sensing components. All are using pull up circuitry. it is fail safe, easy to diagnose. sample like when is open, the pcm reads 5v and pcm knows open wires.
